ATC - SCM50PSL (Pair)
HomeStore

ATC - SCM50PSL (Pair)

ATC - SCM50PSL (Pair)

Select Color
From $6,299.65

Original: $17,999.00

-65%
ATC - SCM50PSL (Pair)

$17,999.00

$6,299.65

The Story

ATC - SCM50PSL (Pair)

Passive Stand Mount Monitor

Description:

    The SCM50P (Passive) or A (Active) are designed to perform at their best in the recording studio or at home with the finest quality hi-fi equipment.

    The monitors’ ability to reproduce music and speech with phenomenal accuracy, transparency and dynamics lies mainly in the SM75-150S soft dome midrange driver. However, recent modifications that include the new ATC SH25-76S tweeter and enhanced port profile have brought about further improvements to all performance parameters.

    Each drive unit in the active model has its own dedicated and individually matched MOS-FET amplifier, while the 234mm/9″ bass driver incorporates ATC’s unique Super Linear Magnet technology. Our active crossover network consists of a wide band-width, electronically balanced input stage with high common mode rejection and very low distortion.

    Like the HF, mid and bass drivers, all electronics are designed and manufactured in-house to create a no-compromise active system. In passive form, the SCM50PSL provides broad and symmetrical dispersion, excellent amplitude and phase characteristics throughout the frequency range.

    Speakers are supplied with stands and fabric wrapped grills.

    Standard Finishes

    Standard Veneers – Cherry, Walnut, Oak & Black Ash.
    Standard Paints – Satin Black, Satin White
    Premium Finishes Available:

    Specifications:

    SCM50P (Passive)

    Drivers: HF 25mm Mid 75mm LF 234mm Super Linear
    Amplitude Linearity ±2dB: 70Hz – 20kHz
    Frequency Response -6dB: 40Hz & 25kHz
    Matched Response: ±0.5dB
    Dispersion: ±80° Coherent Horizontal ±10° Coherent Vertical
    Sensitivity (sine wave): 85dB @ 1W @ 1m
    Max continuous SPL @1m: 112dB SPL
    Crossover Frequency: 380Hz & 3.5kHz
    Input Connector: Binding Posts/4mm banana plugs
    Recommended Power Amplifier: 100 to 1500 Watts
    Nominal Impedance: 8 ohms (5.5 ohm minimum)
    Accessories Inc. (per pair): 2 x Speaker Stands (as shown), 2 x fabric wrapped grills, 8 x M8 x1.25mm stand spikes and nuts.
    Cabinet Dimensions(HxWxD): 717 x 304 x 425mm / 28.23 x 11.97 x 16.73″ (stands add 250mm to height)
    Weight: 41.1kg

    (Sold As Pair)

    ATC - SCM50PSL (Pair) - Image 2

    Details & Craftsmanship

    Every detail has been carefully considered to bring you the perfect product.

    ATC - SCM50PSL (Pair) - Image 3

    Details & Craftsmanship

    Every detail has been carefully considered to bring you the perfect product.

    ATC - SCM50PSL (Pair) - Image 4

    Details & Craftsmanship

    Every detail has been carefully considered to bring you the perfect product.

    ATC - SCM50PSL (Pair) - Image 5

    Details & Craftsmanship

    Every detail has been carefully considered to bring you the perfect product.

    ATC - SCM50PSL (Pair) - Image 6

    Details & Craftsmanship

    Every detail has been carefully considered to bring you the perfect product.

    ATC - SCM50PSL (Pair) - Image 7

    Details & Craftsmanship

    Every detail has been carefully considered to bring you the perfect product.

    Description

    ATC - SCM50PSL (Pair)

    Passive Stand Mount Monitor

    Description:

      The SCM50P (Passive) or A (Active) are designed to perform at their best in the recording studio or at home with the finest quality hi-fi equipment.

      The monitors’ ability to reproduce music and speech with phenomenal accuracy, transparency and dynamics lies mainly in the SM75-150S soft dome midrange driver. However, recent modifications that include the new ATC SH25-76S tweeter and enhanced port profile have brought about further improvements to all performance parameters.

      Each drive unit in the active model has its own dedicated and individually matched MOS-FET amplifier, while the 234mm/9″ bass driver incorporates ATC’s unique Super Linear Magnet technology. Our active crossover network consists of a wide band-width, electronically balanced input stage with high common mode rejection and very low distortion.

      Like the HF, mid and bass drivers, all electronics are designed and manufactured in-house to create a no-compromise active system. In passive form, the SCM50PSL provides broad and symmetrical dispersion, excellent amplitude and phase characteristics throughout the frequency range.

      Speakers are supplied with stands and fabric wrapped grills.

      Standard Finishes

      Standard Veneers – Cherry, Walnut, Oak & Black Ash.
      Standard Paints – Satin Black, Satin White
      Premium Finishes Available:

      Specifications:

      SCM50P (Passive)

      Drivers: HF 25mm Mid 75mm LF 234mm Super Linear
      Amplitude Linearity ±2dB: 70Hz – 20kHz
      Frequency Response -6dB: 40Hz & 25kHz
      Matched Response: ±0.5dB
      Dispersion: ±80° Coherent Horizontal ±10° Coherent Vertical
      Sensitivity (sine wave): 85dB @ 1W @ 1m
      Max continuous SPL @1m: 112dB SPL
      Crossover Frequency: 380Hz & 3.5kHz
      Input Connector: Binding Posts/4mm banana plugs
      Recommended Power Amplifier: 100 to 1500 Watts
      Nominal Impedance: 8 ohms (5.5 ohm minimum)
      Accessories Inc. (per pair): 2 x Speaker Stands (as shown), 2 x fabric wrapped grills, 8 x M8 x1.25mm stand spikes and nuts.
      Cabinet Dimensions(HxWxD): 717 x 304 x 425mm / 28.23 x 11.97 x 16.73″ (stands add 250mm to height)
      Weight: 41.1kg

      (Sold As Pair)
